Pro-9D Overhead 9,000 lbs. Capacity 2 Post Lift (Freight Included)

Sale!
Pro-9D Overhead 9,000 lbs. Capacity 2 Post Lift (Freight Included)

Pro-9D Overhead 9,000 lbs. Capacity 2 Post Lift (Freight Included)

Original price was: $2,027.40.Current price is: $1,067.84.

11 in stock

SKU: ATEXH-PRO-9D-FPD Category:

Description

Atlas Equipment XH-PRO-9D ATEXH-PRO-9D-FPD Pro-9D Overhead 9,000 lbs. Capacity 2 Post Lift (Freight Included)

The Atlas® Pro-9D is the perfect choice for those customers who demand the most lifting capacity at the lowest possible price. This lift can be adjusted to two different height settings: 11′ 8″ or 12′.

The Atlas® Pro-9D has symmetric columns and specially designed arms that can be set in either the symmetric or asymmetric position. The asymmetric/symmetric arm design offers an extremely low lift pad position on the EZ-metric lift arm configuration. This low pad height will allow the operator to position the lift arms under most small cars (with low pick up points) and heavier pick up trucks.

  • 9,000 LB. Capacity
  • Light Commercial Grade
  • “Padded” Shut-Off Bar
  • Asymmetric/Symmetric Arms
  • Clear Floor Design
  • Powder Coat Finish
  • Dual Hydraulic Direct Drive Cylinders
  • Single Point Lock Release
  • Secondary Lock System (SLS)
  • Free 8 Piece Truck Adapter Set
  • Automatic Arm Restraints
  • Mounting Hardware Included
  • 5-year Structural Warranty, 2-year Hydraulic-Power Warranty
  Atlas® Pro-9D Specifications
Capacity 9,000 LB.
Lifting Time Ask Your Salesperson
Overall Height 144″ (12′) or 140″ (11′ 8″)
Overall Width 142 1/2″ (11′ 10 1/2″) (With Power Unit) 133 7/8″ (11′ 1 7/8″) (Without Power Unit)
Outside Column To Outside Column 124 1/8″ (10′ 4 1/8″)
Lift Height (Without Adapters) On Locks: 68″ (5′ 8″) Not On Locks: 71 5/8″ (5′ 11 5/8″)
Maximum Lift Height (With Adapters) On Locks: 74 1/2″ (6′ 2 1/2″) Not On Locks: 77 5/8″ (6′ 5 5/8″)
Padded Bar Height 135 1/4″ (11′ 3 1/4″)
Minimum Arm Height 4 1/2″
Inside Column 109 5/8″ (9′ 1 5/8″)
Column Size 7 1/4″ x 11″
Drive Thru 100 1/4″ (8′ 4 1/4″) (Symmetric Arm Configuration) 92″ (7′ 8″) (Asymmetric Arm Configuration)
Base of Lift 14 1/2″ x 18″
Column Thickness of Steel 5mm
Carriage Thickness of Steel 6mm
Arms Thickness of Steel 6mm
Cable Diameter .375″
Motor/Electrical Requirement 220V single (1) phase.A 30 amp breaker is required.
Oil Requirement 3-5 Gallons AW32/AW46
Requires a minimum of 4″ of concrete with 3000 psi.
Shipping Weight 1450 lbs.

Products with prepaid freight (part numbers ending in -FPD) are only valid for shipment to the continental US.
